7kw 11kw 22kw 3 Phase LCD Screen Type 2 EV Charger Over Temp Protection

7kw 11kw 22kw 3 Phase LCD Screen Type 2 EV Charger Over Temp Protection

Type 2 EV Charger Over Temp Protection

7kw 11kw 22kw EV Charger

3 Phase LCD Screen 22kw EV Charger

Place of Origin:

china

Brand Name:

RC

Certification:

ce, cb, fcc, uL, ROHS

Model Number:

J17 72

Contact Us
Request A Quote
Product Details
Product Name:
LCD Screen Type 2 EV Charger
Max Output Current:
50A
IP Rating:
IP65
Length:
5 Meters
Installation Method:
Wall Mounted
Compatible Vehicle Types:
All EV Models
Display:
LCD Screen
Size:
214*287*87mm
Payment & Shipping Terms
Minimum Order Quantity
1 piece
Price
negotiated
Packaging Details
box package
Delivery Time
5-15 days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
10000pcs a month
Product Description

7kw 11kw 22kw 3 Phase LCD Screen Type 2 EV Charger Over-Temp Protection



Product Description



7kw 11kw 22kw 3 Phase LCD Screen Type 2 EV Charger Over-Temp Protection is a Type 2 EV charger features a 3-phase power supply, offering efficient and rapid charging capabilities for electric vehicles.


Equipped with an LCD screen, this charger provides a user-friendly interface, allowing drivers to easily monitor and control the charging process.
Designed specifically for Type 2 electric vehicles, this charger combines the convenience of Type 2 connectors with the added benefits of a 3-phase power supply and an intuitive LCD screen, ensuring a seamless charging experience.



Specification



Prduct 7kw 11kw 22kw 3 Phase LCD Screen Type 2 EV Charger Over-Temp Protection
Model
RC-EV-7KEU-01
RC-EV-11KEU-02
RC-EV-22KEU-03
Charging capacity
Up to 7KW
Up to 11KW
Up to 22KW
Input/Output power
230VAC+20%-50/60Hz-32A-1phase
400VAC+20%-50/60Hz-16A-3phase
400VAC+20%-50/60Hz-32A-3phase
RCD
30Ma RCD Type A and DC 6Ma RCD function
Standby power
<3W
Measuring accuracy
1%
Communication
Bluetooth/WIFI(Optional) APP
Charging Interface
Type 2 cable 5M
Type 2 cable 5M
Type 2 cable 5M
Special Protection
Over current protection, Residual current protection, Ground protection, Surgeprotection, Over/Under voltage protection,Over/Under frequency protection, Over/Under temperature protection
Warranty 2 years
2 years
Protection
IP65, IK10
Enclosure
Plastic PC94V0
Installation
Wall-mount/Pole- mount
Cooling
Natural cooling
Operating temperature
30°C to +55°C
Humidity
Max. 95%(non-regulating)
Product Dimensions
390*217*105(L *W*H)mm

7kw 11kw 22kw 3 Phase LCD Screen Type 2 EV Charger Over Temp Protection 0

7kw 11kw 22kw 3 Phase LCD Screen Type 2 EV Charger Over Temp Protection 17kw 11kw 22kw 3 Phase LCD Screen Type 2 EV Charger Over Temp Protection 2

7kw 11kw 22kw 3 Phase LCD Screen Type 2 EV Charger Over Temp Protection 3

Factory Introduction



We are an EV charging OEM and ODM manufacturer specializing in charging products, with 8 years of experience. We design and produce high-quality customized charging products for automakers and charging infrastructure operators. We focus on innovation to continuously improve our charging products to meet evolving market needs. By choosing us, you gain access to excellent charging solutions and reliable supply chain support.



Features



we offer a range of innovative products and solutions to meet diverse customer needs. Here are some of our innovative EV Charging solutions:

  1. Smart Charging Stations: Our smart charging stations are equipped with advanced communication technology and intelligent control systems, enabling remote monitoring and management through cloud connectivity and smartphone applications. Users can monitor charging status, adjust charging power, and access real-time data and reports anytime, anywhere.
  2. Fast Charging Technology: We provide high-power fast charging solutions that significantly reduce charging time. This technology is suitable for long-distance travel and commercial applications, offering users a convenient and efficient charging experience.
  3. Smart Payment Systems: Our EV Charging solutions integrate smart payment systems, allowing users to make seamless payments through mobile applications or RFID cards. This convenient payment method enhances the charging experience and management for users.
  4. Integration of Sustainable Energy: We are committed to integrating sustainable energy with EV Charging, offering users green and eco-friendly charging solutions. By integrating with renewable energy systems such as solar or wind, we reduce reliance on traditional energy sources and provide users with more sustainable and cost-effective charging options.
